TBox mini


Central control becomes Android system in seconds

One screen, multiple displays, dual-screen interaction,Cell phone / car screen independent display,Two systems, a variety of ways to play, so that the car machine to say goodbye to monotony,Cell phone and central control interface do not interfere with each other, independent operation!

Quality Upgrade

4 core 3+32G Qualcomm QCM2290 processor.Using 11nm technology, more powerful performance, running fast without pressure


Non-destructive upgrade

Continued operation of the original car control,No need to disassemble the central control / car screen, car box plug and play,Can also be used with the original car knob / touch screen / steering wheel buttons

Mobile Cinema

Support a variety of video APP, a large number of film resources at your leisure to watch,Support downloading games to play online, so that your journey is no longer boring


More systems

Open a new intelligent experience,Built-in wireless CarPlay, wireless Android Auto,Enjoy more cell phone interconnection system

Support multiple satellite navigation systems

Let you travel without worry,Chinese Beidou + US GPS + Russia Glonass Triple positioning, online map for your navigation, avoiding congestion,Quick response to the road, travel smoothly


4G full network

One card for convenience and speed,Built-in 4G full network module, support traffic Internet/WiFi hotspot network,Online video, experience unlimited fun

Tech Specs

Product

Product name

CarlinKit Smart Box

Brand

CarlinKit

Model

CPC200-Tbox Mini

Related Certificates

CE / FCC / ROSH / Telec / BQB

Hardware

System

Android 11.0

CPU

Qualcomm QCM2290, quad-core 64-bit ARM Cortex™-A53 processor @ 2.0 GHz 11nm process

GPU

Adreno™ 702

ROM

3GB of RAM + 32GB of onboard memory

Versions

Eurasian EAU version (Asian, European countries), North American NA version (North America, Canada)

WIFI Frequency

802.11 a/b/g/n/ac, 2.4G+5G

Bluetooth Version

4.2 BLE+5.0 BLE

Power Input

5V±0.2V 1.0A

Power Consumption

Material

ABS+PC

Resolution

Adaptive (maintains original protocol resolution)

Phone OS System

Wireless CarPlay: iPhone 6 and above / iOS 10.0 and above; Wireless Android Auto: Android phones with Android 10.0 and above, some require Android 11.0 and above

Car OS System

Support the original car comes with wired CarPlay function Automotive Head Unit

Language

Multiple languages worldwide, e.g. Arabic, Chinese, English, French

Ports

LED indicator, Type-C female port, TF card holder, SIM card holder

Wires

USB-A to USB-C*1 USB-C to USB-C*1 L=300mm

Cellular network
