CP2A


Sensorless connection

Say goodbye to wired bondage, using the new sensorless connection technology Carplay, sensorless connection can be automatically connected to the car, while not affecting the phone charging, so that car owners say goodbye to all the troubles caused by wired connection

Conditions of use

Only support original car screen

Original car screen supports wired Carplay

iPhone 6 +,iOS 10 +，or

Wireless connection: Android 10.0 +，Wired connection: Android 6.0+


New low power consumption upgrade

The module works with low power consumption, generates less heat, dissipates heat quickly, which is conducive to the module's lasting and stable work, avoiding the problem of high heat and easy to get hot in ordinary modules

5.8GHz＋2.4GHz

Dual-frequency wireless transmission stable and uninterrupted, not easy to be wireless interference, refuse to drop the line, faster transmission rate, lower latency, cell phone connection speed as fast as lightning, to give you a smooth experience!


Plug and Play Instant Conversion

Just plug the product into the original USB/TYPE-C data port, you can realize wireless CarPlay, easily say goodbye to the data cable!

Senseless connection and ready to go

Through WiFi peer-to-peer connection, after the first connection to the Connected Box, the subsequent car can be automatically connected after the start, quickly and conveniently, so you can travel faster.


Original Sound Quality

The Connected Box is compatible with the original car microphone, so when listening to music, making phone calls and using the voice assistant, the sound quality of the original car will continue.

Low latency voice interaction

Through technical means to further reduce the audio delay problem, the response speed is better than ordinary products, giving users a better experience


Don't be tied to the cable

Say goodbye to the bondage of data cable, realize the use of CarPlay and wireless charging at the same time, and further enhance the driving experience.

Original Car Operation

Continued operation of the original buttons

Continues the original knob operation

Support original touch screen operation


OTA Online Upgrade

Enter the upgrade address in the mobile browser to upgrade the version and background settings online.

Lane Level Navigation

High-definition rendering technology to restore the real road scene, positioning accuracy can reach sub-meter level

Tech Specs

Product

Product name

CarlinKit Smart Box

Brand

CarlinKit

Model

CPC200-CP2A

Related Certificates

CE / FCC / PAHs

Hardware

CPU

Atmel AT91SAM9260

WIFI Module

NXP 88W8987(Automotive grade)

MFI

MFI 3959/MFI 3989

WIFI Frequency

5150-5250MHz，5725-5850MHz

Bluetooth Version

5.2 802.11ac

Antenna Specifications

3 dbi Built-in FPC antenna

Power Input

5V±0.2V 1.0A

Power Output

DC 5V±0.2V 1.0A

Power Consumption

0.75W

Material

ABS

Resolution

Adaptive (maintains original protocol resolution)

Car OS System

Support the original car comes with wired CarPlay function Automotive Head Unit

Phone OS System

CarPlay requires iPhone 6 and later, iOS 10 or above; wired Android Auto requires Android 6.0 and above for Android phones

Language

Automatic switching or manual switching according to the language environment of the car

Ports

LED indicator, TYPE-C female port, USB female port

Wires

USB-A to USB-C*1 USB-C to USB-C*1 L=300mm

Product Size

80×46×13mm

Package Size

115×81×37mm

Net weight

0.04kg

Gross Weight

0.126kg

Place of Origin

CHINA

Images

Videos

Packing List

· Packaging Box

· Manual

· CPC200-CP2A Product

· Type-C - Type-C Data Line*1

· Type-C - USB Data Line*1
